A microscope that uses electrons to resolve individual atoms, enabling observation of nanoscale crystal structures.An electron microscope is a type of microscope that uses a beam of electrons instead of light to create highly magnified images of objects. Because electrons have a much shorter wavelength than visible light, they can resolve details far smaller than what optical microscopes can see, down to individual atoms. This capability has made it an essential tool in materials science, biology, and nanotechnology, allowing researchers to observe crystal structures, defects, and even the motion of atoms in real time.
The first electron microscope was built in 1931 by Ernst Ruska and Max Knoll in Germany. Ruska later received the Nobel Prize in Physics in 1986 for his work.
The microscope generates a focused beam of electrons, typically in a vacuum, and directs it onto a sample. The electrons interact with the atoms in the sample, scattering or transmitting through it, and these interactions are detected to form an image. In transmission electron microscopy (TEM), electrons pass through a thin sample, while in scanning electron microscopy (SEM), the beam scans the surface and detects secondary electrons. Advanced techniques, such as aberration correction, improve resolution to the sub-angstrom level, enabling atomic-scale imaging.
Electron microscopes are used in semiconductor manufacturing to inspect chip features, in biology to visualize cellular structures, and in materials science to analyze the atomic arrangement of metals, ceramics, and nanomaterials.
Modern electron microscopes can image individual atoms and even capture the movement of atoms in a crystal, as demonstrated in the title 'Кино для наномира: как увидеть движение атомов'.
